Petrochemical skid

The Chemical Skid is a prefabricated, skid-mounted system that integrates multiple process components, such as pumps, valves, heat exchangers, and instrumentation, into a single, compact unit. This modular design allows for ease of installation, commissioning, and maintenance, significantly reducing onsite construction time and costs. The use of high-quality materials and advanced manufacturing techniques ensures long-term durability and resistance to the harsh conditions typically found in chemical and petrochemical environments.

Our Chemical Skid is specifically designed for applications in the chemical, petrochemical, and related industries, including refineries, chemical plants, and gas processing facilities. It can be easily adapted to various process requirements, offering flexibility and scalability to meet changing project needs. The skid module's compact design also makes it an ideal solution for offshore and remote locations, where space is limited and accessibility is challenging.

In summary, our Chemical Skid is a high-performance, cost-effective solution for the chemical and petrochemical industry. With its modular design, ease of installation, and versatility, this skid module offers superior performance and reliability in a wide range of applications. As a trusted manufacturer, we are committed to providing our clients with innovative, high-quality products, including our Chemical Skid, to meet their unique project requirements. Choose us as your partner for reliable and efficient skid solutions in the chemical and petrochemical sectors.

All measurement instruments and equipment in the skid unit are installed outdoors within the process area of the facility, suitable for open-air installations. The flow computer and rack are housed in the client's control room.

This project involves a single crude oil quality flow meter skid to be installed at the terminal station. The metering system follows a two-in-service-and-one-backup principle, with three branches each having a calibration interface at the site.

Design requirements for the metering system include an outlet and discharge line at the lowest point of each branch, with all discharges connecting to a central on-site connection. All process valves (excluding instrumentation) utilize flanged connections.

The Petrochemical skid system is designed with a logical layout for ease of future field operation and maintenance. The supplier provides a realistic and effective three-dimensional visual aid for the client's review prior to finalization. Additionally, a pre-manufacturing review session is held with the client, the design team, to ensure consensus on the final design before proceeding with production.

A platform for operations and safety measures is incorporated within the metering skid to facilitate operator access and maintenance of equipment.

In terms of color coding for instruments and pipelines, the specific colors will follow industry standards or as per the client's preferences and specifications, which should be clearly indicated in the design documentation.
